| Element | Quantity |
| Terminal | 6 |
| NPN(1S) | 11 |
| NPN(12S) | 1 |
| PNP(1S) | 8 |
| Resistor(15kΩ) | 22 |
| Parameter | Conditions | Limit | Unit | ||
| Min. | Typ. | Max. | |||
| Operating supply voltage range | 5 | V | |||
| Internal Consumption current | IN1～3=GND | 0.36 | mA | ||
| Input threshold voltage | 0.46 | V | |||
| Output saturation voltage | IOUT=5mA | 0.30 | V | ||
| Rising delay time | 0.7 | us | |||
| Falling delay time | 0.3 | us | |||
